Components and Accessories : Silicon Heaters
  >
Type 9BFV
Type 9BFV
Type 9BFV
Silicone boots for cables and wires output with temperature sensor and temperature limiter on flexible flat silicone heaters. Assembly by bonding or vulcanization.
Components and Accessories
Silicon Heaters
Check PDF
Click to see more languages available in the datasheet
Product applicable fields
    The product does not currently have its own area
product presentation

These enclosures include a stainless-steel removable locking device for the power cable and an internal and external grounding terminal. The flexibility of the silicone makes it possible to use cables with a diameter slightly greater (up to 15%) than that of the passage opening. They also comprise a degassing orifice and a «funnel» orifice for filling the silicone resin, which are cut after curing.

Part number Compatible devices Features
9BFV1 Naked welding thermocouples, glass bead NTC, flat chip Pt100. Disc thermostat type 4903

Minimum band width: 100mm

Connection: 5 conductor external cable

Silicone resin filling: Yes
9BFV2 Dia. 5mm temperature sensors with 30mm maximum probe length

Minimum band width: 100mm

Connection: 5 conductor external cable

Silicone resin filling: Yes
9BFV3 Dia. 6mm temperature sensors with 30mm maximum probe length

Minimum band width: 100mm

Connection: 5 conductor external cable
Silicone resin filling: Yes
